Choosing a weighbridge for a crusher plant is not really a purchase decision about steel. It is a decision about how every load you sell will be measured, proved and billed for the next ten years, and about how much of that will happen without anyone retyping a figure.
Plants usually compare quotations on capacity and price. What decides whether the weighbridge is a help or a headache sits further down the specification: the indicator’s output, the verification position, the siting, and whether the supplier will connect it to your billing system or leave you with a printed slip.
This post goes through those choices in the order you have to make them: pit or pitless, capacity and platform length, load cells, the indicator, Legal Metrology verification, integration, and siting and maintenance.
Pit or pitless
This is the first decision because it dictates civil work, drainage and how much land you need on either side.
| Pit type | Pitless | |
|---|---|---|
| Space needed | Less, because vehicles drive on at deck level | More, because ramps sit at both ends |
| Civil work | Excavation, retaining walls and a drained pit | Foundation plus approach ramps |
| Water and dust | Pit collects both, so drainage and pumping matter | Open underneath, easier to hose down |
| Access for service | Confined space under the deck | Load cells reachable from the side |
| Suits | Tight sites and yards where land is the constraint | Dusty, wet quarry sites with room to spare |
For a crusher plant the balance usually tilts towards pitless, because quarry sites carry dust and runoff and a pit full of slurry is a maintenance job you inherit forever. Choose pit type when land at the gate is genuinely short.
Sizing a weighbridge for a crusher plant
Work these out from your own traffic, not from the supplier’s standard model. Two questions settle it.
First, what is the heaviest gross weight you will ever weigh, including the day you load a hired multi-axle trailer to its limit? Size capacity above that, and ask the supplier in writing what safe overload the structure and the load cells allow.
Second, what is the longest vehicle you will weigh in one pass? Measure from the front axle to the rear-most axle of the longest trailer that comes to your gate, and add clearance at both ends. A platform that is short by half a metre turns every long trailer into a two-part weighment, which is slower and much easier to dispute.
If you cannot justify a full-length platform today, ask what it costs to extend the same foundation later.
Load cells and the junction box
Load cells are the part that fails in a quarry, and they fail from water, dust, surges and rodents rather than from weight.
- Ask for the ingress protection rating of the load cells, the cable glands and the junction box, in writing.
- Ask whether the cells are analogue or digital, and what diagnostics the indicator gives you when one cell drifts.
- Ask for surge and lightning protection at the junction box, which matters on an open quarry site.
- Ask how long a replacement cell takes to reach your plant, and keep the part number in your file.
- Ask for the calibration record from commissioning, cell by cell, not just a single certificate.
The indicator and its output
The indicator is the part that decides whether your weighbridge can talk to your software. Treat it as a data device, not a display.
Ask the supplier for the output options on the exact model being quoted: serial output, a network port, or both. Then ask for the protocol document that describes the data string, because that document is what your software vendor will work from. A supplier who cannot produce it is telling you something useful.
Also settle these before you sign:
- Does it output continuously, or only on a stable-weight command?
- Can two systems read the same output, so the display and the billing software do not fight?
- Is the printer separate from the data output, so a printer failure does not stop billing?
- Does the indicator store weighments internally if the link to the office drops?
Legal Metrology: verification and stamping
A weighbridge used in trade has to be verified. Section 24 of the Legal Metrology Act, 2009 requires every person who has a weight or measure in possession in circumstances indicating that it is being used, or is likely to be used, in any transaction to have it verified before putting it into use.
Rule 27 of the Legal Metrology (General) Rules, 2011 sets the re-verification periods: twenty-four months for weights, capacity measures, length measures, tape, beam scale and counter machine, sixty months for storage tanks, and twelve months for any other weight or measure, which is where an electronic weighbridge sits. Re-verification is also required after any repair, dismantling or reinstallation, so a load cell replacement is not just a service call.
Under the state Legal Metrology (Enforcement) Rules, the officer stamps the instrument with a stamp of uniform design showing the number allotted, and marks the year and quarter of stamping. A certificate of verification is issued, and it has to be exhibited in a conspicuous place in the premises where the instrument is used. A weighbridge is verified where it stands, so plan for the officer’s visit at the plant.
The penalty for using an unverified weight or measure sits in Section 33 of the Act: a fine of not less than two thousand rupees and up to ten thousand rupees for a first offence, and for a second or subsequent offence imprisonment which may extend to one year, or fine, or both.
Keep this file at the plant
- Current verification certificate, displayed where the weighbridge is used.
- Date the current stamping expires, with a reminder set a month before.
- Commissioning calibration record and every service report since.
- Any re-verification done after repair or reinstallation.
Integration with billing
The gap between a weighbridge and a billing system is where revenue leaks. If the operator reads a display and types the figure into a slip, you have an unverifiable number, and you also have a manual step at the busiest moment of the day.
Insist that gross, tare and net come into the dispatch record directly from the indicator, that the dispatch slip, the permit reference and the tax invoice all carry the same net, and that nobody can edit a captured weight without it being recorded. This is the whole argument behind weighbridge integration and revenue leakage, and it is also what finally ends the era of keeping weighments in a spreadsheet.
Siting and maintenance
Put the weighbridge where a loaded truck can approach straight and stop level. Sloped or curved approaches put uneven load on the cells and produce readings that drift with the driver.
Leave a straight, level approach at both ends, drain the area so water does not pond under or beside the deck, and keep the space under the platform clear of spillage. In a crusher yard, fines build up under the deck and start taking load, which shows up as a weight that will not return to zero.
Set a routine: check zero at the start of each shift with an empty platform and log it, clean under the deck, check cable entries, and record any knock from a loader bucket. A knock that is logged is a warranty claim. One that is not logged is your problem.
Frequently asked questions
How often does a weighbridge need re-verification?
Rule 27 of the Legal Metrology (General) Rules, 2011 puts any other weight or measure, which covers an electronic weighbridge, on a twelve month cycle, and re-verification is required again after any repair, dismantling or reinstallation.
Can we weigh at a public weighbridge instead of installing our own?
You can, and the e-way bill rules recognise it: movement of up to twenty kilometres within the same state to a weighbridge for weighment and back to the consignor’s premises is exempt, provided the goods move with a delivery challan. It works for occasional loads, but every trip costs time at the gate.
Do we need a full-length platform if most of our vehicles are tippers?
Size for the longest vehicle you will actually weigh, not the average. Axle-by-axle weighment of a long trailer on a short deck is slower and is the first thing a customer challenges.
The indicator has a printer. Is that enough?
A printed slip proves a reading was taken. It does not stop the figure being retyped, rounded or lost between the gate and the invoice, which is the part that costs money.
Connecting it to the rest of the plant
A weighbridge earns its cost when the reading becomes a dispatch, a royalty entry and an invoice without a second keystroke. Quipu’s Stone Crusher and Quarry ERP takes gross, tare and net straight from the weighbridge into the dispatch and vehicle log, carries the mineral-wise royalty on the same entry, and raises the tax invoice from it.
